Deliver network audio directly to speakers with a compact, DSP-equipped Class D amplifier featuring Dante 2-channel digital I/O. The KanexPro AUD-DTE-2CHAMP is a 150W Class D amplifier that decodes Dante network audio and drives low-impedance (4Ω/8Ω) stereo speakers or constant-voltage (70V/100V) distributed speaker lines — with balanced analog line-level I/O for legacy integration.
Built-in DSP provides 31-band graphic EQ, per-output delay (0–50ms), independent input gain and volume control, and five recallable presets. The amplifier accepts Dante PCM 2-channel audio at up to 96KHz/24-bit alongside balanced stereo line input. A rear-panel speaker impedance switch selects Lo-Z stereo (2×75W @ 4Ω/8Ω), bridged mono (1×150W @ 8Ω), or Hi-Z constant voltage (1×150W @ 70V/100V). Control via RS-232, LAN, and Web GUI. 5–12V trigger input and auto standby for energy-efficient installations. Half-rack/full-rack mountable.
Dante 2-channel digital audio input and output (PCM, 44.1K–96KHz, 16/24-bit) for seamless networked audio distribution
Balanced or unbalanced stereo line-level analog input and output (max 2Vrms) for integration with legacy analog sources and processors
Class D amplifier delivers 2×75W @ 4Ω/8Ω stereo, 1×150W @ 8Ω bridged mono, or 1×150W @ 70V/100V constant voltage
Rear-panel speaker impedance switch selects Lo-Z (4Ω/8Ω) or Hi-Z (70V/100V) output mode without reconfiguration
Built-in DSP with 31-band graphic EQ (−10 to +10dB), per-output delay (0–50ms), independent input gain and master volume control
Five recallable presets store complete audio configuration for rapid scene switching in multi-use spaces
5–12V trigger input for external mute control; auto standby (0–120 min) for energy-efficient operation
Control via RS-232 (115200 baud), LAN (Web GUI), and TCP/IP (port 8000) — half-rack/full-rack mountable
