4K/60 Fiber Optics Input Card

4 X 4K/60 Fiber Optics Input Card for Flex Matrix Pro.

Skip to product information
1 of 1

KanexPro

SKU: FLEX-PROFIB-IN

UPC: 813982023802

View full details

The Kanexpro FLEX-PROFIB-IN is a high-performance 4K fiber-optic Input card designed received 4K video signals transmitted over fiber optics. This card is part of the Kanexpro FLEX PRO MATRIX series. Additionally, the FLEX-PROFIB-IN is fully compatible with the FLEX-PROFIB-TX, enabling seamless integration within the FLEX PRO MATRIX system. This compatibility ensures efficient signal management and distribution, making it a reliable choice for complex AV environments requiring high-resolution video and audio transmission.

Kanexpro FLEX-PROFIB-IN is equipped with advanced features like stereo audio extraction, and RS232 control, making it ideal for professional AV setups.

Key Features:

  • 4K Video Transmission: Supports 4K video signals over fiber optics, making it ideal for high-resolution video applications.
  • Part of FLEX PRO MATRIX Series: Fully compatible with other components in the FLEX PRO MATRIX series, allowing for efficient AV setups in complex environments.
  • Stereo Audio Extraction: The output card features advanced audio extraction capabilities, making it suitable for professional AV setups where both high-quality video and audio are crucial.

·       RS232 Control: Includes RS232 control for enhanced remote management, making it ideal for sophisticated AV installations requiring centralized control.

Technical

InputCard ports

 4 X 1 LC Fiber Input Port

Connector Type

 LC

Signal Type

Fiber w/ Adaptive Single Mode & Multimode Processing

Optical Loss Budget:

 Single Mode 9 dB, Multimode 8 dB

Maximum Receiver Sensitivity

Single mode -15dbm, Multi-mode -16dbm

Video Resolution:

Up to 3840x2160 60Hz 4:4:4 (8bit)

Operating Distance:

Single-mode 1.24 Mile (2 KM), Multi-mode 984 mile (300 m)

Normal Peak Wavelength

1550nm, 1310nm

Analog Audio Port

4 X 5-pin Phoenix stereo audio for Insertion / Extraction



No diagram available.

No panel image available.

No downloads available.
