24×60 4K60 Modular Matrix Switcher with Built-In Video Wall

Sixty displays from one chassis. The FLEX-MF24X60 is the highest-output matrix in the standard FLEX line — purpose-built for convention centers, casino floors, large hotels, and campus-wide signage where output count matters more than input count. Five output card slots and three input slots route 24 4K60 sources to 60 screens with video wall, quad view, and independent scaling built in.

Every output independently scaled. CAT cards reach 230ft. CEC powers displays by zone. 7" touch + Web GUI + RS-232 + TCP/IP. Cards shared across all FLEX chassis sizes.

• Up to 24 HDMI 2.0 inputs and 60 outputs via hot-swappable modular cards (HDMI, CAT, DisplayPort)
• 4K/UHD 60Hz at 18Gbps with full HDCP 2.2 and HDR support
• Built-in video wall up to 4×3 (12 displays) with bezel compensation; quad view displays four sources on one output
• Independent output scaling adjusts resolution per channel for mixed-display environments
• CAT output extends 4K signals up to 230ft (70m) via single cable using FLEX-CATRX receivers
• CEC display control for zone-based power management across screens
• 7" front-panel touchscreen for on-site switching, preset recall, and system monitoring
• RS-232, TCP/IP, and Web GUI control for Crestron, Control4, Savant, and other platform integration
